MITNF125HGV3P56-80 Zoom

CIRCUIT BKR-80A THERM ADJ 70kA 3P T/A 56-80A

World Super-V Series MCCBs
Part No. MITNF125HGV3P56-80
Mitsubishi ElectricClick to see more products from Mitsubishi Electric
Features

World Super-V Series MCCBs

  • Moulded case circuit breakers (125/160/250 amp frame size)
  • Compact high performance circuit breakers
  • Interrupting capacities of 36kA, 70kA, 150kA and 200kA are available
  • Service breaking capacity (lcs) identical to Ultimate breaking capacity (lcu)
  • Body size 105mm(w) x 165mm(h) x 68mm(d) for 3 pole version
  • Available in 2, 3 and 4 pole versions
  • Also available with earth leakage protection in the same compact body
  • Reverse connection permitted on standard breakers with no earth leakage protection
Details

Details

Part No. MITNF125HGV3P56-80
Brand Mitsubishi Electric
Unit Of Measure Each
Compendium Page # 583 (click to view)
